Siemens SINAMICS S120 Combi Equipment Manual

Cabinet design and EMC
12.7 Connection system
SINAMICS S120 Combi
Manual, (GH9), 07/2016, 6SL3097-4AV00-0BP5
305
12.7.3
Current-carrying capacity and derating factors for power cables and signal
cables
The current-carrying capacity of PVC/PUR-insulated copper cables is specified for routing
types B1, B2 and C under continuous operating conditions in the table with reference to an
ambient air temperature of 40 °C. For other ambient temperatures, the values must be
corrected by the factors listed in the "Derating factors for deviating conditions" table.
Table 12- 10 Current-carrying capacity according to EN 60204-1 for 40 °C ambient temperature
Cross-section
Current-carrying capacity, effective; AC 50/60 Hz or DC
for routing type
mm
2
B1
A
B2
A
C
A
Electronics
0,20
–
4,3
4,4
0,50 – 7,5 7,5
0,75
–
9
9,5
Power
0,75
8,6
8,5
9,8
1,00
10,3
10,1
11,7
1,50
13,5
13,1
15,2
2,50
18,3
17,4
21
4
24
23
28
6
31
30
36
10
44
40
50
16
59
54
66
Installation types
B1 cables in conduits or installation ducts
B2 multi
-core cables in conduits or installation ducts
C cables along walls/panels without conduits and installation ducts
Table 12- 11 Derating factors for deviating conditions
Ambient temperature [°C]
Derating factor according to EN 60204-1 Table D1
30
1,15
35
1,08
40
1,00
45
0,91
50
0,82
55
0,71
60
0,58
