Siemens SINAMICS S120 Combi Equipment Manual

Motor Modules Booksize Compact as expansion axes
6.5 Meaning of the LEDs on the Motor Module Booksize Compact
150
SINAMICS S120 Combi
Manual, (GH9), 07/2016, 6SL3097-4AV00-0BP5
6.5
Meaning of the LEDs on the Motor Module Booksize Compact
Table 6- 5 Meaning of the LEDs on the Single Motor Module/Double Motor Module
Status
Description, cause
Remedy
RDY
DC LINK
OFF OFF The electronics power supply is missing or outside the
permissible tolerance range.
–
Green -- The component is ready for operation. Cyclic DRIVE-
CLiQ communication is taking place.
–
Orange The component is ready for operation. Cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is present.
–
Red The component is ready for operation. Cyclic DRIVE-
CLiQ communication is taking place.
The DC link voltage is too high.
Check the line supply volt-
age.
Orange
Orange
DRIVE-CLiQ communication is being established.
–
Red -- This component has at least one fault.
Note:
The LED is activated regardless of whether the corre-
sponding messages have been reconfigured.
Remedy and acknowledge
fault
Green / Red
(0.5 Hz)
-- Firmware is being downloaded. –
Green / Red
(2 Hz)
-- Firmware download is complete. Wait for POWER ON. Carry out a POWER ON
Green / Or-
ange
or
Red / Orange
-- Component recognition via LED is activated. This func-
tion can be parameterized (see SINAMICS S120/S150
List Manual).
Note:
Both possibilities depend on the status of the LED when
activating.
–
WARNING
Danger to life through electric shock due to applied DC link voltage
Irrespective of the state of the LED "DC LINK", hazardous DC-link voltages can always be
present.
Death or serious injury can result when live parts are touched.
• Observe the warning information on the component.
