The SINAUT Configuration Tool
6.4 The connection configuration
TIM DNP3
144 System Manual, 06/2014, C79000-G8976-C253-03
Further functions for this object are then available over the menu bar, over the buttons of the
toolbar or often over a context menu that opens when you select an object with the right
mouse button.
Buttons in the properties dialogs have the following functions:
●
Applies the entries made and closes the dialog.
●
Discards the entries made and closes the dialog.
Exception:
In the "Subscriber Administration, the Cancel button is not available. In this case, the
dialog is closed without entering changes by clicking on the close button [x] in the right-
hand top corner of the header line of the dialog.
●
Opens the online help.
How to work with the functions of the individual configuration tools "Connection
Configuration", "Subscriber Administration" and "TD7onTIM" is explained in the following
sections.
The connection configuration
6.4.1
Configuring the connections
The DNP3 connections
In DNP3 systems, connections are always configured between the following subscribers:
● Between the CPU of a station and the CPU of the DNP3 master station
● Between the CPU of a station and a control center PC
● Between two CPUs of stations (only with direct communication in Ethernet / dial-up
network)
