The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
191
Figure 6-14 Object "Bin04B_R" with the selected channel "Binary receive" in the list box and its
parameter dialog below
To simplify parameter assignment, channels along with their parameter assignment can be
copied. If a data object requires more than one channel with the same parameter
assignment (except for the input or output address) and if the parameter settings have been
completed for one channel, this channel along with its parameters can be copied.
When you copy channels, the channel you are copying is not added to the existing channels
since the number of channels is fixed per data object. The channel selected prior to paste is
overwritten by the copied channel and its parameters.
To copy, follow the steps outlined below:
1. Select a channel in the list box.
2. In the shortcut menu (right mouse button), select the "Copy" menu or use the key
combination <Ctrl>+C.
3. Select a different channel of the same object or the channel of another data object of the
same type.
4. Insert the channel after parameter assignment using the shortcut menu (right mouse
button) "Insert" or use the key combination <Ctrl>+V.
The selected channel is overwritten by the copied channel and its parameters.
