Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
291
Incorrect synchronization mode on MPI. Master mode expected.
No further module exists on MPI bus/party line.
External / internal WAN interface: A subscriber could not be synchronized following restart.
Error detected in time-of-day synchronization.
Bad time-of-day message received from DCF77 module.
Bad time-of-day message received from DCF77 module.
Bad time-of-day message received from DCF77 module.
Error in synchronization request.
Messages from diagnostic server
Error occurred installing the diagnostic server.
Installation of diagnostic server completed.
Error occurred sending a message.
0663
Entering state: Error occurred receiving a message.
Exiting state: Error occurred receiving a message.
0664
Entering state: Heap memory overflow.
F460 Exiting state: Heap memory overflow eliminated.
0665
Entering state: Unknown PDU received.
F860 Exiting state: Unknown PDU received.
Incorrect firmware version installed on TIM.
0667
Entering state: All [n] LAN connections are disrupted.
Exiting state: [x] of [n] LAN connections are OK.
Message buffer of TIM records was deleted.
0669
Entering state: DNP3 Message Monitor
Exiting state: DNP3 Message Monitor off
066A
Entering state: Extended diagnostics on
Exiting state: Extended diagnostics off
Extended diagnostics - modification
Error occurred in system status list query.
Messages from P bus server
Installation of P bus server aborted.
Unknown message received from task.
Error occurred receiving a message.
06B3
Entering state: Power outage on P bus.
Exiting state: Power supply on P bus OK.
06B4
Entering state: I/O disabled by CPU.
F260 Exiting state: I/O enabled by CPU.
Module on P bus not capable of communication.
F960 06B6 Parity error in P bus communication.
