SIGLENT TECHNOLOGIES SDS1104X-E User Manual

SDS1000X-E User Manual
112
WWW.SIGLENT.COM
Units for Math Waveforms
Use the channel function menu to set the unit of each channel to “V” or “A”. The
oscilloscope math operation includes units as below:
Math Operation
Unit
Addition (+)or subtraction (-)
V, A
multiplication (*)
V
∧
2, A
∧
2 or W
division (/)
None, Ω (Resistance unit Ohms), S (conductance
unit Siemens)
FFT
dBVrms, Vrms, dBm, dBArms, Arms
differential (d/dt)
V/S or A/S (V/second or A/second)
integral (∫dt)
VS or AS (V*second or A*second)
square root ( )
V
∧
1/2 or A
∧
1/2
