SDS1000X-E User Manual
161
WWW.SIGLENT.COM
System Setting
System Status
Press Digital→NextPage2/2 → System ,then select the System Status option to view
the digital system information , including software version, hardware version, and serial
number. After finished, press the return soft key to quit the interface of system
information.
Figure 96 Digital System Information Interface
Update
The software version file of the Digital can be updated directly via U-disk. Follow the steps
below:
1. Insert U-disk with firmware update file (*.ads) to USB host interface on the front panel
of the oscilloscope. Then a message “USB Flash Drive detected!” will be displayed.
2. Press Digital→NextPage2/2→System →Update
3. Expand the U disk directory, Select the firmware file (*.ads), then press the Press to
update, an upgrade progress bar will be display on the interface.
