SDS1000X-E User Manual
175
condition is meeting (the absolute value of input voltage is higher than 4V±0.5V). When
overvoltage protection occurs, a message will be displayed and the output is disabled.
Default
Press Utility →NextPage4/4→ AWG→ Setting→ Default to recover the default values of
AWG (Sine, 1.000 KHz, 4.000Vpp, 0.0mVdc, High-Z, Sync output off, OVP On).
Zero Adjust
Press Utility→ NextPage4/4→ AWG→ Setting→ Zero Adjust. The AWG can be
calibrated by using Auto mode or Manual mode. The adoption standard of AWG calibrated
is: when AWG outputs 0V DC signal, the corresponding channel at 1mv/div gear' mean
value of oscilloscope is rang in ±1mv.
Auto mode: This mode can only be performed with the channel1 of oscilloscope.
Connect the output of AWG to the oscilloscope’channel1, press the Auto soft key,
then the AWG starts to automatic calibrate, and displays ”Zero Adjust Success!”.
Manual mode: The AWG can be manually calibrated through any channel on the
oscilloscope.
Take channel 2 as an example:
a) Connect the output of AWG to the oscilloscope’ channel 2, open the channel 2,
and set DC coupling, open bandwidth limit, Probe is 1X.
b) Adjust the voltage of channel 2 channel to 1mv/div, and make the waveform
visible in the oscilloscope interface, press the Measure and measure the mean
value of channel 2.
c) Press the Manual and rotate the knob to adjust the waveform, so that the mean
value of the observed CH2 will be in the range of ±1mv, and then press the Save,
the oscilloscope displays "Zero Adjust Success!".
Systems
System Status
Press Utility→NextPage4/4→AWG→System, then select the System Status option to
view the AWG’s system information, including software version, hardware version, and
serial number. After finished, press the return softkey to exit the system information page.
