SDS1000X-E User Manual
142
Clear Display
Press the Display button on the front panel to enter the DISPLAY function menu; press the
Clear Display softkey to clear all the waveforms displaying on the screen and acquire and
display new waveforms.
Grid Type
To select grid type
1. Press the Display/Persist button on the front panel to enter the DISPLAY function
menu.
2. Press the Next Page softkey to go to the second page of the Display function menu.
3. Press the Grid softkey; and then turn the Universal Knob to select the desired grid
type. Press the Grid softkey continually can also select the grid type.
There are 3 kinds of grid types that are available. Select the grid type according to your
really demand.
Display 14X8 grid type
Display 2X2 grid type
Display without grid
Intensity
Do the following steps to adjust waveform intensity:
1. Press the Display/Persist button on the front panel to enter the DISPLAY function
menu.
2. Press the Next Page softkey to go to the second page of the Display function menu.
3. Press the Intensity softkey; and then turn the Universal Knob to select the desired
value. The default value is 50%, and the range is from 0% to 100%.
Increasing the intensity lets you see the maximum amount of noise and infrequently
occurring events. Reducing the intensity can expose more detail in complex signals as
shown in the following figures.
