Create a New File or Folder
This operation is only valid in external storage. The oscilloscope supports English input
method. The file name or folder name can contain letters, numbers, underscores and
spaces. Let’s use an example to introduce how to create a file or folder.
Example: create a file or folder named “SDS2013ab”
1. Press the Save/Recall button on the front to enter the SAVE/RECALL function menu.
2. Press the Save softkey, and then turn the Universal Knob to select one of the type (if
select Setups, please set the Save To option to External).
3. Press the Press to Save softkey to enter the SAVE/RECAL file system.
Press the New softkey to open the interface shown as the picture below. It divides into
two parts: name input area and keyboard area.
Figure 89 Input Keyboard
4. To delete the name in the name input area, press the Backspace softkey
continuously to delete the character one by one.
