SDS1000X-E User Manual
202
Navigate
SDS1000X-E（only 4 channels scope supports this function）provides three navigate type:
Search Event, Time, History Frame.
Time Navigate
1. Press the Navigate on the front panel to enter the NAVIGATE function menu.
2. Press the Type softkey In the NAVIGATE function menu, then select Time.
3. There are two ways to navigate time.
a) Press the Time softkey, then, turn the Universal Knob to select the desired
value or press the Universal Knob then enter the value by the pop keyboard.
b) Press the navigation keys ◀■▶ on the front panel to play backward, stop, or
play forward in time. You can press the ◀ or ▶ keys multiple times to speed up
the playback. There are three speed levels: Low Speed, Medium Speed, High
Speed.
History Frame Navigate
When the History function is enabled, you can use the navigation controls to play through
the acquired frames.
1. Press the Navigate on the front panel to enter the NAVIGATE function menu.
2. Press the Type In the Navigate Menu, then select History Frame.
3. Press the Frame Num softekey, then there are two ways to navigate history frames.
a) Turn the Universal Knob to select the desired number or press the Universal
Knob then enter the number by the pop keyboard.
b) Press the navigation keys ◀■▶ on the front panel to play backward, stop, or
play forward.
Search Event Navigate
When the Search function is enabled and acquisitions are stopped, you can use the
