SDS1000X-E User Manual
129
WWW.SIGLENT.COM
Measure
The oscilloscope provides measurements of 36 waveform parameters and the statistics. It
contains voltage, time and delay parameters.
Voltage and time parameters are under Type option. The results of the last five selected
measurements are displayed at the bottom of screen and above the menu. Delay
parameters are under the All Measure submenu. Set the Delay option to On to display all
the delay parameters.
The contents of this chapter:
Type of measurement
Automatic measurement
All measurement
Gate measurement
Clear measurement
