SDS1000X-E User Manual
143
Note: Waveform intensity adjustment affects analog channel waveforms only (not math
waveforms, reference waveforms, digital waveforms, etc.).
Grid Brightness
Do the following steps to adjust the grid brightness:
1. Press the Display button on the front panel to enter the DISPLAY function menu.
2. Press the Next Page softkey to go to the second page of the Display function menu.
3. Press the Graticule softkey; and then turn the Universal Knob to select the desired
value. The default value is 40%, and the range is from 0% to 100%.
Transparence
Transparence can be used to adjust the transparence of the message box of cursor,
measure, Pass/Fail and all pop-up menus to an appropriate value to observe the date
more conveniently.
Under Cursor or Measure or any other menu operation, if want to change the
transparence of the message box, do the following steps:
1. Press the Display button on the front panel to enter the DISPLAY function menu.
2. Press the Next Page softkey to go to the second page of the Display function menu.
3. Press the Transparence softkey; and then turn the Universal Knob to select the
desired value. The default value is 80%, and the range is from 20% to 80%.
