SIGLENT TECHNOLOGIES SDS1104X-E User Manual

SDS1000X-E User Manual
166
WWW.SIGLENT.COM
Quick-Cal
Quick calibration can correct the measurement deviation caused by temperature, so that
you can get more accurate measurements
If the ambient temperature of your current operating oscilloscope is unstable, press Utility
→ Quick-Cal softkey to select On to enable quick calibration.
Sound
When the sound is enabled, you can hear the sound of the beeper when you press a
function key or a menu softkey or when the prompt message pops up.
Press the Utility button on the front panel to enter the UTILITY function menu; then press
Sound softkey to select or to turn on or off the sound.
Language
The oscilloscope supports multiple language menu, Chinese/English help and prompt
messages.
1. Press Utility button on the front panel to enter the UTILITY Function menu.
2. Press the Language softkey; and then turn the Universal Knob to select the desired
language. Then push down the knob to select the language.
The languages that currently available are Simplified Chinese, Traditional Chinese,
English, French, German, Spanish, Russian, Italian, and Portuguese.

SIGLENT TECHNOLOGIES SDS1104X-E Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Record Length	14 Mpts
Max Input Voltage	400 V (DC + AC Peak)
Vertical Resolution	8 bits
Display Resolution	800 x 480
Input Coupling	DC, AC, GND
Operating Temperature	0 °C to +50 °C
Display	7-inch TFT-LCD
Input Voltage Range	±400 V
Waveform Capture Rate	100, 000 wfs/s (Normal Mode), 400, 000 wfs/s (Sequence Mode)
Interfaces	LAN
Input Impedance	1 MΩ ± 1%
Trigger Types	Edge, Pulse, Video, Slope, Pattern
