SDS1000X-E User Manual
188
Option Management
The SDS1000X-E provides multiple options to fulfill your measurement requirements.
Please contact your SIGLENT sales representative or SIGLENT technical support to
order the corresponding options. You can view the options currently installed on the
oscilloscope or activate the newly purchased option license codes through this menu.
Do the following steps to install the option on the oscilloscope:
1. Press the Utility button on the front panel to enter the UTILITY function menu.
2. Press the Next Page softkey to go to the third page of the UTILITY function menu.
3. Press the Options softkey to enter the OPTION function menu.
Figure 114: OPTION Function Menu
4. Press the Type softkey; then turn the Universal Knob to select the module to be
installed and push down the knob to confirm.
5. Press the Install softkey to enter the LABEL function menu to input the license.
Figure 115 LABEL Function Menu
Turn the Universal Knob to select character
Push down the Universal Knob to confirm the characters
Press the Press To Install when license key input done,
Press the Clean softkey or the Backspace softkey to delete the incorrect
character.
