Trigger Type
The oscilloscope provides abundant advanced trigger functions, including various serial
bus triggers.
 Edge trigger
 Slope trigger
 Pulse trigger
 Video trigger
 Window trigger
 Interval trigger
 DropOut trigger
 Runt trigger
 Pattern trigger
