SDS1000X-E User Manual
25
Enable the Channel
The oscilloscope provides 2/4analog input channels and provides independent vertical
control system for each channel. As the vertical system setting methods of every channel
is the same, this chapter takes CH1 as an example to introduce the setting method of the
vertical system.
Connect a signal to the CH1 channel connector; and then press the CH1 button in the
vertical control area (VERTICAL) at the front panel to enable CH1.
The channel setting menu is displayed at the bottom of the screen and the channel label
at the right side of the screen. The information displayed in the channel label is related to
the current channel setting.
After the channel is turned on, modify the parameters such as the vertical scale, the
horizontal time base and the trigger mode according to the input signal to make the
waveform display easy to observe and measure.
Note: to turn off the channel, press the channel button twice.
