SDS1000X-E User Manual
185
1. Press the Utility button on the front panel to enter the UTILITY function menu.
2. Press the Next Page softkey to go to the second page of the UTILITY function menu.
3. Press the Next Page softkey to go to the third page of the UTILITY function menu.
4. Press the Do Self Test softkey to enter the SELFTEST function menu.
5. Press the LED Test softkey to enter the keyboard test interface, as the picture shown
below.
Figure 112 LED Test
6. According to the prompting information displaying on the screen, press the Single
button continually to light the button lights one by one. The first time to press the
Single button, the Run/Stop button displays red, and the second press the Run/Stop
button displays green. Then the other button lights will be lighted one by one. At last
all the lights will be lighted at the same time.
7. Press the Run/Stop button to exit the LED test program.
