SDS1000X-E User Manual
10
WWW.SIGLENT.COM
Figure 9 4-Channel Scope Front Panel Overview
Description
NO.
Description
LCD Display
12
Horizontal Control
Universal Knob
13
Trigger Control
Common Function Menus
14
Menu on/off
Clear Sweeps
15
Menu Softkey
Run/Stop
16
One- Button shortcut for Save
Decode
17
Analog Channel
Auto Setup
18
Power Button
Navigate
19
USB Host
History
20
Digital Inputs
Default
21
Probe Compensation/ Ground Terminal
Vertical Control, Math, REF and
Digital
