SIM5350 AT Command Set
Write Command Responses
+CMGW: <index>
OK
ERROR
If text mode(AT+CMGF=1):
AT+CMGW=<oa>/<da>[,<t
ooa>/<toda>[,<stat>]]<CR>
Text is entered.
<CTRL-Z/ESC>
If PDU mode(AT+CMGF=
0):
AT+CMGW=<length>[,<sta
t>]<CR>PDU is entered.
<CTRL-Z/ESC>
+CMS ERROR: <err>
Defined values
<index>
Integer type; value in the range of location numbers supported by the associated memory and start
with zero.
<oa>
Originating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <tooa>.
<tooa>
TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>).
<da>
Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <toda>.
<toda>
TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
<length>
Integer type value indicating in the text mode (AT+ CM GF =1) the length of the message body
<data> > (or <cdata>) in characters; or in PDU mode (AT+ CM GF=0), the length of the actual TP
data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length).
<stat>
Integer type in PDU mode (default 0), or string type in text mode (default "REC UNREAD");
indicates the status of message in memory; defined values:
0 "REC UNREAD" received unread message (i.e. new message)
1 "REC READ" received read message
2 "STO UNSENT" stored unsent message (only applicable to SMs)
3 "STO SENT" stored sent message (only applicable to SMs)
4 "ALL" all messages (only applicable to +CMGL command)
7 "DRAFT"
SIM5350_ATC_V1.02 6/9/2014
106
