User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Housing dimensions 96 x 96 x 100 mm (small housing - 3,5” Display)
or 144 x 144 x 100 mm (big housing - 5,7” Display)
Mounting hole 90.5 x 90.5 mm (small housing - 3,5” Display)
or 137 x 137 mm (big housing - 5,7” Display)
Assembly depth
Panel thickness
102 mm
max. 5 mm
Operating temperature
(depending on version)
0°C to +50°C
or -20°C to +50°C
Storage temperature
(depending on version)
-10°C to +70°C
or -20°C to +70°C
Humidity
Altitude
5 to 90% no condensation
up to 2000 meters above sea level
Screws tightening max. torque 0,5 Nm
Max. connection leads diameter 2,5 mm
2
Safety requirements according to: PN-EN 61010-1
installation category: II
pollution degree: 2
voltage in relation to ground: 300V AC
isolation resistance: >20MΩ
isolation strength between power supply and
input/output terminal: 1min. @ 2300V (see
Fig. 4.1
)
EMC PN-EN 61326-1
Weight
340g (only base, see
Fig.
4.8
)
* check the current list of measurement modules at producer's website
** see the full specification in the Appendices
4. DEVICE INSTALLATION
The unit has been designed and manufactured in a way assuring a high level of user
safety and resistance to interference occurring in a typical industrial environment. In order to
take full advantage of these characteristics installation of the unit must be conducted correctly
and according to the local regulations.
- Read the basic safety requirements on page
5
prior to starting the installation.
- Ensure that the power supply network voltage corresponds to the nominal
voltage stated on the unit’s identification label.
- The load must correspond to the requirements listed in the technical data.
- All installation works must be conducted with a disconnected power supply.
- Protecting the power supply connections against unauthorized persons must
be taken into consideration.
10
!
