8.3. UI4N8, UI4D8, UI8N8, UI8D8 – MIXED UIN/UID MODULES
Fig. 8.7. Mixed measurement modules
The
Fig. 8.7
shows terminals placement of UIN/UID modules. Inputs are gathered into groups
to make connections easier. All ground terminals of a particular module are common, but
separated from power supply and other modules. If it is necessary to make measurements
with different ground potentials, several UIN/UID modules have to be installed into
MultiCon
CMC-99/141
unit.
241
n01
n02
n03
n04
n05
n06
n07
n08
n09
n10
n11
n12
n13
n14
n15
n16
n17
n18
n19
n20
GND
IN9
IN10
IN11
IN12
4 x 0-20mA
GND
IN5
IN6
IN8
IN7
4 x 0 - 100kΩ
IN1
IN2
IN4
IN3
GND
4 x 0 - 100kΩ
UI4N8
8 resistance
+ 4 current and 4 voltage inputs
GND
IN13
IN14
IN15
IN16
4 x 0-10V
n01
n02
n03
n04
n05
n06
n07
n08
n09
n10
n11
n12
n13
n14
n15
n16
n17
n18
n19
n20
UI4D8
4 current and 4 voltage
+ 8 digital inputs
GND
IN1
IN2
IN3
IN4
4 x 0-20mA
GND
IN5
IN6
IN7
IN8
4 x 0-10V
COM 9-12
IN9
IN10
IN11
IN12
IN17
COM 13-16
IN13
IN14
IN15
IN16
IN18
n01
n02
n03
n04
n05
n06
n07
n08
n09
n10
n11
n12
n13
n14
n15
n16
n17
n18
n19
n20
n21
n22
n23
n24
n25
n26
n27
n28
n29
n30
GND
IN9
IN10
IN11
IN12
4 x 0-20mA
GND
IN13
IN14
IN15
IN16
4 x 0-20mA
GND
IN5
IN6
IN8
IN7
4 x 0 - 100kΩ
IN1
IN2
IN4
IN3
GND
4 x 0 - 100kΩ
UI8N8
8 resistance
+ 8 current and voltage inputs
GND
IN17
IN18
IN19
IN20
4 x 0-10V
GND
IN21
IN22
IN23
IN24
4 x 0-10V
n01
n02
n03
n04
n05
n06
n07
n08
n09
n10
n11
n12
n13
n14
n15
n16
n17
n18
n19
n20
n21
n22
n23
n24
n25
n26
n27
n28
n29
n30
GND
IN1
IN2
IN3
IN4
4 x 0-20mA
GND
IN5
IN6
IN7
IN8
4 x 0-20mA
UI8D8
8 current and voltage
+ 8 digital inputs
GND
IN9
IN10
IN11
IN12
4 x 0-10V
GND
IN13
IN14
IN15
IN16
4 x 0-10V
COM 17-20
IN17
IN18
IN19
IN20
IN25
COM 21-24
IN21
IN22
IN23
IN24
IN26
