Simex multicon cmc-99 User Manual

User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
8.7. RT4 , RT6 – RTD MEASUREMENT MODULES
Fig. 8.14 RTD modules
Most important parameters of RT4 and RT6 modules:
RT4 RT6
Number of inputs 4 6
Hardware measurement ranges 0÷325Ω,
0÷3250Ω
0÷325Ω,
0÷3250Ω
Hardware resolution
range ±325Ω
range ±3250Ω
0.01Ω
0.1Ω
0.01Ω
0.1Ω
Covered MultiCon CMC-99/141
measurement ranges *
RTD
resistance
Pt100, Pt'100, Pt'50, Pt500,
Pt'500, Pt1000, Cu50, Cu'50,
Cu100, Cu'100
0-300Ω
0-3kΩ
Pt100, Pt'100, Pt'50, Pt500,
Pt'500, Pt1000, Cu50, Cu'50,
Cu100, Cu'100
0-300Ω
0-3kΩ
252
RT4
4 RTD inputs
n08
n09
n10
n11
n12
n04
n05
n06
n07
n01
n02
n03
n16
n13
n14
n15
IN1 IN2 IN3 IN4
RT6
6 RTD inputs
IN1IN2IN3
IN4IN5
n08
n09
n10
n11
n12
n04
n05
n06
n07
n01
n02
n03
n16
n13
n14
n15
n20
n17
n18
n19
n24
n21
n22
n23
IN6
RTD 4-wire
mode
IN1
n01
n02
n03
n04
RTD 3-wire
mode
IN1
n01
n02
n03
n04
RTD 2-wire
mode
IN1
n01
n02
n03
n04
