7.8.5. Logical Channels - Set point value mode
In
Set point value
mode the user defines constant value which can be displayed on the
screen, used for calculations in other channels (e.g. in math functions, controllers etc.) or as a
data source for built-in or external outputs which will control any object.
The parameters of the
Logical channels
in
Set point value
mode should be:
–
Name
- it gives the name to the logical channel,
–
Mode=Set point value
- in this parameter user selects source type of data for logical
channel,
–
Unit
- this parameter allows the user to define any unit,
–
Set point value
- this parameter is visible only if
Edit button=disabled
, after
pressing the button next to
Set point value
parameter appears in window allowing
entry of a value (see
Fig. 7.6
), this value will be a source of data for this Logical
channel.
–
Edit button
- this parameter allows you to activate the button in the panel data
(see
Fig. 7.49
), this parameter has two options:
•
disabled
- the button is disabled on the display, in this case the data source of
logical channel will be the value set in the
Set point value
parameter,
(see
Fig. 7.50
),
•
enabled
- this button is active, in this case the data source of logical channel will
be the value set after pressing the button, but the initial value is the number
written in
Set point value
parameter, before setting the
Edit button
parameter
to
enabled
,
–
Button mode
– parameter is visible only in case when
Edit button
parameter is set
on
enabled
, and
Format
parameter in
Displaying
parameter block is set on
binary
,
it has two options:
•
bistable
– pressing and releasing the button will cause permanent change of
state,
•
monostable
- pressing and releasing the button will cause that the button on
0,1 second will switch from
OFF
state to
ON
state, and after that time, it will
switch again to
OFF
state,
92
disabled
Hardware input
Hardware output monitor
Modbus
Set point value
Math function
Controller
Profile/timer
Profile/timer (cycle counter)
Data from other channel
Mode
