User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
5.2. HARDWARE CONFIGURATIONS
The functionality of
MultiCon CMC-99/141
can fit to the user's needs. The
base
of the
MultiCon CMC-99/141
contains: the main processor, display with touch-screen, Switch Mode
Power Supply (in one of two versions:
19V...
24
...50V DC 16V...
24
...35V AC
and 85V..230..260V
AC) and basic communication interfaces: USB and RS485, see
Fig. 4.8
- most far left
connectors. All other modules are optional and can be installed inside the device according to
customer's needs. Next to the basic connectors is the slot for an advanced communication
module. In the simplest version this module can be equipped only with rear USB Host
connector (this is standard for the IP-65 version of the
MultiCon CMC-99/141
). The full
version of this module contains also 2 additional serial ports (RS485 and RS485/RS232) and
a 10Mb Ethernet RJ-45 connector (see
Fig. 4.22
).
Three slots designed for built-in hardware inputs and outputs are installed on the right
side of the case (see
Fig. 4.8
, terminals marked: slot A, slot B and slot C). The number and
size of these terminals varies depending on module type. Brief descriptions of available
modules are shown in
Fig. 4.9
÷
Fig. 4.22
. Measurement and actuator modules are constantly
being developed, so the current list of available modules varies (visit manufacturers website
to check current list of
MultiCon CMC-99/141
modules).
Basic measurement modules are:
– 4/8/16/24x Voltage/Current input module,
– 16/24x NTC/Voltage/Current/Digital input module,
– 6x Isolated current input module,
– 2/4x flowmeter + 2/4x current input,
– 2/4x pulse input + 2/4x current input,
– 4/6x RTD input module,
– 4/8/12x TC input module.
– 8/16/24x Digital input
– 3/5x universal input
– 2/4x universal counter input
– 2/4x hourmeter input
Output modules are:
– 8/16/24x SSR driver module,
– 8/12x Relay 1A/250V module,
– 4/6x Relay 5A/250V module,
– 2/4/6/8x IO passive current output.
Communication module:
– ACM,
– ETU,
– USB,
35
