User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Compensation
parameter which allows tu manually compensate
sensor error, written here value will be added or subtracted from
measured sensor value,
automatic
allows to compensate the difference between real temperature
and that measured by the sensor,
Actual temperature
parameter in which user enters actual
temperature near the sensor, which is measured by more reliable
thermometer,
Compensate
button which activates the compensation; value which
is written in
Actual temperature
parameter will be from now on used
for compensation,
Compensation
read only parameter; displays voltage value
calculated to compensate temperature measurement,
User should remember, that after changing the sensor, new settings in Wire compensation
menu should be made.
Connectors temperature input parameters are:
Name
each built-in input already has a name given by the device and user cannot
change it, for description of
Name
parameter see
Fig.
7.75
.
Unit
– parameter which displays measurement unit -
°C
,
Mode
– parameter which displays
Temp. of connectors
,
Low limit
defines measurement level bellow which in logical channel will be
displayed
Lo
state,
High limit
defines measurement level above which in logical channel will be
displayed
Hi
state,
Offset
parameter which allows to add or subtract constant value to temperature
measured by connectors temperature sensor,
7.9.5.9. Optoisolated digital inputs modules
D
modules are equipped with eight, sixteen or twenty four digital inputs, see
Appendices 8.9. D8, D16, D24 OPTOISOLATED DIGITAL INPUTS MODULE
. This inputs
can be used individually, but also in groups of four or all inputs available in module.
Measurement results are presented in decimal system.
D modules parameters are:
Name
each built-in input already has a name given by the device and user cannot
change it, for description of
Name
parameter see
Fig.
7.75
.
Filter time
defines minimal time that has to elapse from last input state change, if
this change wants to be noticed; Each input has the possibility to sets its own Filter
time, even if this input is part of another, different set of this parameter do not
disturbs their work,
7.9.5.10. Optoisolated universal counters modules
CP
modules can be equipped in two or four universal counters inputs (see
Appendices
8.10. CP2, CP4 OPTOISOLATED UNIVERSAL COUNTERS MODULES
). Each counter
can be configured individually and is equipped with two counting inputs:
Inp[n]1
,
Inp[n]2
,
programming input
Prog[n]
, reset input
Res[n]
, where
n
means counter number from 1 to 4.
148
