User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Fig. 7.96. The relation between the input and output for External output
Note!
If external output is active (see the parameter
Output active=yes
in the
Chapter 7.15.3.2. Modbus MASTER - Device channels parameter block
) for
undefined
Source
parameter (e.g. a Logical channel in the
Mode=disabled
) or for
undefined
Input
and
Output levels
parameter block (every parameter has value 0)
the
MultiCon CMC-99/141
send to Slave device value
'0'
.
170
i
-4 -2 0 2 4 6 8 10 12 14 16 18 20 22 24 26 28
0
5
10
15
20
25
30
Input value
Output value
Upper level
Input levels
Lower level
Upper level
Output levels
Lower level
