User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Fig. 8.12. FT4 module and PNP type sensor connection scheme
248
NPN
4,7 kΩ
Power supply
(depending on version)
1
2
8
5
6
7
3
4
SERVICE
+24V DC ±5% (Imax. = 200mA)
digital input
0/15..24V DC
RS-485
GND
GND
A+
B-
isolated
FT4
4 pulse inputs
+ 4 current inputs
n15
n16
n17
n04
n05
n13
n14
n01
n02
n03
n04
n05
n01
n02
n03
n06
n10
n11
n07
n08
n09
n12
GND
IN5
IN6
IN7
IN8
4 x 0-20mA
COM4
Inp42
Inp41
COM3
Inp32
Inp31
COM2
Inp22
Inp21
COM1
Inp12
Inp11
