Fig. 2.1. Basic structure of the multichannel device
Process control with built-in outputs can be done with programmable hysteresis and
delays of the outputs control. It is possible to control (linearly or bistably) remote
modules. Controlling processes can drive built-in physical outputs or virtual outputs
which can be used as inputs to
logical channels
.
8
Build-in analog input
Buid-in binary input
External input (RS-485)
Profiles/timers
Controller
Mathematical & logical combination data
States of hardware & virtual outputs
Set point values
Display
Numeric, logical or text values
Charts & bars
Needles indicators
Grouping data
Interface
Build-in analog output
Build-in binary output
External output (RS-485)
Interface
Reading data via Ethernet
Reading data stored on the
flash drive
Interface
