5. Assembly
EN
29
5
Fig. 6
5.2.1 Port dimensions, assembly holes, and minimum mounting dimensions
262
70
271
90
1
170
247
153
4,25
1050
C
B
A
Minimum mounting dimensions
A = width: 330 mm
B = height 450 mm
C = depth 350 mm
