SKF LMC 301 series User Manual

11. System configuration
11.6 Zone 1 Settings (main line basic settings)
Pump settings => Zone 1 Settings
Step Key Display Description
Configuring the zones - only in Supervisor password level
1
• Open the System configuration menu (see Chapter 11.3)
• Use <down/up arrow key> to select Pump settings (1-3)menu
• Press <OK control key>
• You will enter the Pump settings (1-3) menu
• Use <down/up arrow key> to select Zone 1 Settings
• Press <OK control key>
•
)You will enter the Zone 1 Settings menu.
The following settings can be made:
o Cycle Control Step 2, Specification of cycle parameters such as Timings, Release/
Counter, and Lube Load
o Lube Control Specification of zone valves, see following sections
o Alarm Step 3
System configuration
Pump 1 settings
Zone 1 Settings
Cycle Control
Lube Control
Alarm
SelectBack
SelectBack
SelectBack
Amount of pumps
Pump 1 settings
Set Params to Default
Condition on delivery
Pump settings
Zone 1 Settings
Zone basic settings
