11. System configuration
Pump settings => Zone 1 Setting => Cycle Control => Timings
Step Key Display Description
Zone 1 Settings/ Cycle Control Cycle control for the respective zone
2
)The following settings are available:
o Timings
o Release/Counter
o Lube Load
• Use <down/up arrow key> to select the Timings menu
• Press <OK control key>
)The following settings are available:
o Control Mode/Normal Cycle Time/Heavy Cycle Time
• Use <Select arrow key> to select Control Mode menu
• Use <down/up arrow key> to select time controlled or counter ctrld menu
• Press <Save control key>
• Use <down arrow key> to select the Normal Cycle Time menu
• Press <Select control key>
• Use <down/up arrow key> to enter the value
• Press <Save control key>
• Use <down arrow key> to select the Heavy Cycle Time menu
• Press <Select control key>
• Use <down/up arrow key> to enter the value
• Press <Save control key>
• Press <Back control key>
Cycle Control
Timings
Release/Counter
Lube Load
Timings
Select
Back
SelectBack
Control Mode
[<< time controlled >><<counter ctrl]
Normal Cycle Time
[0000: 00: 00]
Heavy Cycle Time
[0000: 00: 00]
Zone basic settings
