SKF LMC 301 series User Manual

3. Technical data
EN
25
3
3. Technical data
Characteristics, design
Mounting position Vertical, see Page 14
Dimensions (LxWxH) 270 x 170 x 90 mm
Display 60x30 mm128x64 pixels
Ambient conditions
Altitude AC ≤ 2000 m / DC ≤ 5000 m
Ambient/operating temperature AC -10 to +50°C
Ambient/operating temperature DC -40 to +70°C
Maximum relative humidity 80% to 31°C, declining
linearly to 50%
relative humidity at 40°C
The LCD display only operates down to - 20°C
Storage temperature - 40 to + 70°C
Application
≤ 150 VAC or 24 VDC, indoor/outdoor
3
)
UL overvoltage category III,
pollution category 2
> 150 to ≤ 240 VAC, only permissible for indoor,
UL overvoltage category II,
pollution category 2
Connectivity via terminal strip
Inputs: 10 count, short-circuit-proof, 2 of which analog
Outputs: 8 count, relay outputs NO-contact 8A
Residual ripple relative to
operating voltage ±5% acc. to DIN 41755
3.1 General technical data
Characteristics, design
Protection and monitoring
Current limit Sustained short-circuit-proof
Overload-proof/open-circuit-proof Yes
Protection class
1
)
4
)
IP 65, protection class only with
permissible cable glands PG-M20, without
UL certification
Power consumption (electronic consumers)
Internal fuse (LMC Controller) 3 A
Input AC
Input voltage 100-240 VAC (50/60 Hz)
Fusing provided by customer (slow) 4 A (100-240 VAC)
Input DC
2
)
3
)
Input voltage 24 VDC ±10%
Fusing (slow) 10 A
1) Cable gland/blind plug - see page 91
2) Protective measures that must be taken for designated usage:
“Protective Extra Low Voltage” (PELV) and “Safe Extra Low Voltage”
(SELV).
3) Application for outdoors (outdoors installation) was not tested in the
context of/certification with the UL standard.
4) The protection class for the LMC 301 Controller was not tested as
part of the UL certification.
