SKF LMC 301 series User Manual

6. Configuration by operator/local admin
6.4 Dual Line system examples
Several examples of Dual Line central-
ized lubrication systems with an LMC 301
Controller are listed below and can be used
as the basis for local admins to make their
settings.
The individual examples are divided into
three sections.
Section 1 is a brief textual description of the
structure of the single-line centralized lubri-
cation system shown.
Section 2 shows the structure of the
particular single-line centralized lubrication
system (system design) with the associated
LMC 301 terminal diagram.
Section 3 shows the customer program-
ming of the LMC 301 Controller via its
display and keyboard (see Chapter 6.2).
