6. Configuration by operator/local admin
6.3.9 Pump 1 timings
General
Up to three pumps can be connected to the
LMC 301 Controller; the maximum amount
of zones (main lines) that the Controller can
control is limited to three.
Up to three main lines (zone 1 to zone 3) can
be programmed per pump.
These can be accessed in the Main menu
under:
Pump 1 Timings
Zone 1 Settings
Zone 2 Settings
(if 2nd line present)
Zone 3 Settings
(if 3rd line present)
Depending on the access level, the following
settings can be made:
o Relief settings (only with 3/2 directional
solenoid valves)
o Zone settings with:
o Lube Load
o Normal Cycle Time
o Heavy Cycle Time
o Monitoring Time
o Holding Time
EN
56
