Solar-Log 2000 User Manual

114
Using the Solar-Log™ Android App
8.7 App settings
Tap on the symbol in the toolbar at the top right corner of the screen.
The navigation screen then appears.
•
Update
•
Today
•
Settings
•
End
Fig.: Day curve and menu
•
Select Update to update the plant's data.
•
Select Today to leave the yield data and to switch to the current daily overview.
•
Select End to quit the application.
By selecting Settings from the menu, the following categories are available:
• General
• Slide show
• Legal Disclaimer
Fig.: General settings.

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
