Foot Switch Commands
T
he
>>B&E8B274A
b
uttons in the middle of the
'
@0=A?>@B(B8;8BG
w
indow allow the two momentary foot switches which
can be connected to the Matrix to have any USB or listed DAW command assigned to them. Both the HUI and MCU protocols
contain dedicated codes for use with foot switches which actuate the DAW transport Play and Record functions. These are
shown in the command list as
#;0G>>B&E8B27 and %42>@3>>B&E8B27.
I
n addition, there is an extra SSL command which has been created specifically for use with the foot switch:
@B8AB'0;:102:
&E8B27
enables the talkback function of the @B8AB button to be assigned to a foot switch.
Note that the foot switch must be held down to keep talkback open.
KVM Hot Key
The ) >B4G, located towards the top left of the '@0=A?>@B(B8;8BG window, does not appear on the Matrix console.
The button is only used on setups where there is more than one computer connected to Matrix. The ) >B4G can be
programmed with a command to a USB KVM switch, telling it to switch between computer ports. When programmed, it outputs
a USB command whenever its layer is selected using the console’s *,%&' buttons, telling the KVM switch to
select the USB port connecting to the computer on which the layer’s DAW or MIDI device is hosted. The specific commands
used by your KVM switch should be found in its operating manual.
