Solid State Logic Matrix 2 User Manual

Appendix B – Technical Specifications
Performance Figures
Headroom < +26dBu @ 1kHz (< 1% THD)
Line In to Direct Out
Frequency Response ±0dB at 20Hz, +0/–0.1dB at 20kHz, –1dB at 80kHz
Noise < –89dBu 20Hz – 22kHz
T
HD < 0.002% @ 1kHz (+24dBu, 22kHz filter)
Line to Aux Bus Out
Frequency Response ±0dB at 20Hz, +0/–0.1dB at 20kHz
Noise < –93dBu (no channels routed)
< –76dBu (all channels routed, faders at 0dB)
THD < 0.002% @ 1kHz (+24dBu, 22kHz filter)
Line To Mix/Rec Bus Out
Frequency Response ±0dB at 20Hz, +0/–0.1dB at 20kHz
Noise < –89dBu (no channels routed)
< –77.5dBu (all channels routed, faders at 0dB, pan at centre)
THD < 0.002% @ 1kHz (+24dBu, 22kHz filter)
Matrix Power Supply
Parameter Value Unit Notes
Width 106 mm
Height 202 mm including feet
Depth 306 mm excluding lead and connectors
Weight 5 kg
Heat Dissipation 45 W approximately
Noise - - fanless
Voltage 100 – 240 V ± 10%
Current 2.0 – 1.0 A
Connector (mains input) IEC320 10A Male
Matrix Console
Parameter Value Unit Notes
Width 946 mm
Height 228 mm including feet
Depth 724 mm excluding connectors
Weight 25 kg
Heat Dissipation 130 W approximately
Noise - - fanless
Connector (DC power input) BICC 12-pin Male
Appendix B - Technical Specifications
115
Matrix
2
Owner’s Manual

Solid State Logic Matrix 2 Specifications
