Appendix C – Audio Connectors and Pinouts
Tip(T) Ring(R) Sleeve(S)
1/4" Jack
Pinout for headphone:
Tip Right channel
Ring Left channel
Sleeve Ground
Pinout for footswitch:
Tip Control input (connect to 0V to activate)
Ring n/c
Sleeve 0V
Stereo
Plug
Connectors Viewed From Wiring Side
1
2
3
4
5
14
15
16
17
6
7
8
9
1
0
18
19
20
21
1
1
1
2
1
3
22
23
24
25
1
2
3
4
5
14
15
16
17
6
7
8
9
10
18
19
20
21
11
12
13
22
23
24
25
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
D-Type Multipin
25-way
Dimensions: 55 x 15mm (approx.)
Cable Dia: 8mm (typical)
9-way
Dimensions: 35 x 15mm (approx.)
Cable Dia: 7mm (typical)
Plug
Socket
Plug
Socket
Free Plug
Free Socket
1
2
3
1
2
3
XLR 3-Pin
Pinout for balanced analogue audio (Mini LS):
Pin 1 - Screen/Ground
Pin 2 - Hot (+ve)
Pin 3 - Cold (-ve)
Pinout for balanced digital audio (AES3):
Pin 1 - Screen
Pin 2 - Hot (+ve)
Pin 3 - Cold (-ve)
Connectors Viewed
F
rom Wiring Side
Appendix C - Pinouts
