The Total Recall Tab
T
he
'
>B0;%420;;
t
ab is the second tab from the left in the Matrix Remote:
This tab controls the Matrix Total Recall function, which allows you to store and recall Matrix settings used in the Current Title.
All of the settings on the desk which you are likely to need to remember are stored as part of the Total Recall snapshot, as listed
on Page 63.
Note that the settings of any X-Racks which are connected to Matrix are also included in the Total Recall function. For X-
Racks running software version 1.2/4 or below, up to 4 X-Racks can be included. For X-Racks running software version
1.3/0 or above, up to 6 X-Racks can be included. See your X-Rack manual for details of X-Rack Total Recall.
A number of the TR functions described over the following pages can be accessed directly from the Matrix console using the
TR menu in the SSL soft keys. See Page 46 for more details.
Taking a TR Snapshot
To take a snapshot of the desk’s settings, press the '0:4'%&=0? button located to the right of the window. The snapshot
will then appear in the current Title’s snapshot list in the centre of the '>B0;%420;; window, as well as in the '>B0;%420;;
folder in the #@>942BA tab.
It is also possible to take a snapshot directly from the Matrix front panel via the
TR
set of SSL soft keys – see Page 44.
Naming a TR Snapshot
Snapshots are named ‘'%=’ where ‘=’ is the lowest unused TR number within that Title However, you can edit this name by
right clicking (Mac: ctrl+click) on the required snapshot and selecting %4=0<4 from the drop-down menu. Type the name in the
!4E!0<4 pop-up which appears, and press ". Note that the snapshot number will be retained at the front of the snapshot
name.
Deleting a TR Snapshot
To delete a snapshot, right click (Mac: ctrl+click) on the required TR and select 4;4B4 from the drop-down menu. Press "
in the warning pop-up which appears.
Chapter 4 - Matrix Remote
60
Matrix
2
Owner’s Manual
