Matrix Internal Wiring Diagram
The following diagram depicts all of the console’s internal wiring connections. Each connection on the drawing is marked with a
connector name shown within italic braces, {}, which is the name found printed on the assembly’s PCB, adjacent to the connector
a
nd a loom reference which is physically labeled on each cable within the console.
The exception to this are the ribbon cables on the LCD displays, these cables do not have a loom reference.
Appendix G - Service
159
Matrix
2
Owner’s Manual
