Eventually you will personalise your Profiles. As part of the personalisation process, Profiles for other DAW packages can be
created using the Pro Tools default Profile for HUI DAWs, and the Logic default Profiles for MCU DAWs (see Chapter 6).
H
owever, for now, the important thing is to make sure you assign each DAW layer the right protocol. If you are running a DAW
other than those listed above, please refer to its manual to establish which control protocol it uses.
‰ Using the
0G4@ buttons, located in the middle of the * tab towards the top, select the
layer you are planning to assign to your first DAW.
‰ In the #@>58;4&4BC? area found in the top left corner of the * tab, select the correct
default Profile from the &4;42B43#@>58;4 drop-down list.
‰ If the new Profile you select uses a different protocol than that which was previously
selected, a pop-up will appear asking you to reboot Matrix. Press ". If you have more
layers to set up, you can select the Profiles on all of them before rebooting. Once you have
selected all the Profiles required for now, switch the console off and on again.
Note that once the protocol has been changed, the soft key assignments are locked out until the reboot is performed.
Please refer to Chapter 6 for more on DAW layers.
Chapter 1 - Setup
12
Matrix
2
Owner’s Manual
