Below the Small Fader is the Large Fader pan control. This is always
associated with the Large Fader and is always in circuit.
The Large Fader CUT switch is automated. This and all the other
automated switch objects in the channel make use of the Match and
Play switches fitted above the Large Fader CUT and SOLO. See the J
Series Computer Operator’s Manual for more details.
As with the Small Fader Solo switch, the Large Fader SOLO switch
can act as a destructive solo, a post pan listen (AFL), a pre-fade listen
(PFL) or as a Solo In Front function. This last mode provides a mix of
the AFL signal and dimmed Main Mix to the monitors. The different
solo functions are selected with the solo mode switches in the
console’s centre section. These switches also include a SOLO
CLEAR switch, ALT which makes all solo switches intercancelling,
FLEET which makes them momentary, and SOLO LINK which links
Large and Small Fader Solo cut busses.
The Large Fader is motorised and, like all SSL Ultimation systems,
can switch the audio via a VCA to allow Trim updates etc. See the J
Series Computer Operator’s Manual for more details.
The Large Fader can be assigned to one of the 8 master control
faders in the centre section, by using the group select switch at the
bottom of the fader. Selecting HARD GROUP SETUP on the Motion
Control panel enables the select switches. A short press of the
individual select switches increments the group number in that
fader’s 7-segment display; a slightly longer press decrements.
Console Overview
1-5
8.9.94
SOLO
CUT
M P
ST
PST
LF
PRE
LF
SF
MIX
ISO
SOLO CUT
C
RL
C
L R
PAN
trim
abs
REC
10
5
0
5
10
20
30
40
60
0
0
LF
MIX
trim
abs
alt
status
SL978
SSL
10
5
0
5
10
20
30
40
50
group
24
#
