Spectra Precision Focus 6 User Manual

Spectra Precision Focus 6 5" Total Station User Guide 183
Communications 9
Coordinates record
Observation record
08KI pt northing easting elevation desc
1–4 08KI Coordinates record identifier (fixed text)
5–8 (2x),
5–20 (33)
pt Point number
9–18 (2x),
21–36 (33)
northing Northing of the coordinate
19–28 (2x),
37–52 (33)
easting Easting of the coordinate
29–38 (2x),
53–68 (33)
elevation Elevation of the coordinate
39–54 (2x),
69–84 (33)
desc Feature code
09MC stnpt pt sd va ha desc
1–4 09MC Observation record identifier (fixed text)
5–8 (2x),
5–20 (33)
stnpt Station point number
9–12 (2x),
21–36 (33)
pt Observed point number
13–22 (2x),
37–52 (33)
sd Slope distance
23–32 (2x),
53–68 (33)
va Vertical angle
33–42 (2x),
69–84 (33)
ha Horizontal angle
43–58 (2x),
85–100 (33)
desc Feature code
