Spectra Precision Focus 6 5" Total Station User Guide 51
Getting Started 3
3. Press [ENT].
4. Enter the target height or select the height from the HT stack.
Note – To display the HT stack, press the
Stack softkey. The HT stack stores the last 20
HT values entered.
Setting the current temperature and pressure
1. Press
[HOT] to display the HOT menu.
2. Do one of the following:
– Press [2].
– Select Temp-Press.
3. Press
[ENT].
4. Enter the ambient temperature and pressure. The ppm value is updated
automatically.
Selecting the target set
A target set specifies settings for the target type, the
prism constant, and height of target. When you change
the selected target set, all three settings are changed.
You can use this function to quickly switch between two
types of target, such as a reflector sheet and a prism.
You can prepare up to five target sets.
Press
[HOT] to display the HOT menu. Then either press [3], or select Target and press
[ENT]. A list of the five target sets appears. To select a target set, either press the
corresponding numeric key (
[1] through [5]), or use [^] or [v] to highlight the target set in
the list and press
[ENT].
To change the settings defined in a target set, highlight the target set in the list. Then
press the
Edit softkey.
B
Tip – HT can be left blank in the target set. If you leave it
blank, the current HT value is always applied to the measurement.
When a target set is selected, the Type and Const values are copied to both [MSR1] and
[MSR2] settings, and to the measurements in Qcode. If you have specified a value for HT,
this value is also copied to the current HT.
Type Prism/N-Prism
Const –999 to 999 mm
HT –9.990 to 99.990 m
