Camera system
Modern video cameras on the industrial truck
and colour monitors in the driver's cab provide
the operator with a better overview of the
working area.
The cameras can only perform the desired
function if they are set correctly. To achieve
an optimum image display, the cameras must
be adjusted individually. The system is activa-
ted as soon as the industrial truck is switched
on.
CAUTION
Assistance system
Camera systems are passive systems. They do not
interfere with the functionality of the industrial truck.
The operator is responsible for working in a safe
manner.
Before setting the truck in motion, the operator must
check that the camera system is functioning properly
and has the correct settings. If the camera system is
not functioning correctly, the system must be re-
paired or adjusted before setting off.
Rear view camera
One camera mounted centrally on the lift mast
facing towards the drive unit. One monitor in
the driver's cab.
This camera should be set in such a way that
the field of vision matches the braking area of
the industrial truck. If the operator sees an ob-
stacle on the monitor, there is enough time to
react and stop.
Rear view camera for entering aisles
Two cameras mounted on the rear of the driv-
er's cab with a view of the guide rollers (MZF)
and the roadway in the direction of the drive
unit. Two monitors in the driver's cab. This
version can also be used as a replacement for
rear-view mirrors in closed cabs (wind deflec-
tor, cold store).
These cameras should be set so that one of
the rail guide rollers (MZF) or the corner con-
tour of the chassis (IZF) is visible in each of
Special equipment
7
Camera system
1375231 804 2502 EN - 04/2020
