Displays
1.1 Emergency off switch pressed 4 Not used
1.2 Foot switch required 5.1 *MPSE in operation
1.3
Two-hand operation on the left re-
quired
5.2 *MPSE has detected a fault
1.4
Two-hand operation on the right re-
quired
6Not used
1.5 Barrier open 7.1 *Navigation, combination operation
1.6 PIN entry expected 7.2
*Navigation, destination is located on the
left-hand side
1.7 RFID entry expected 7.3
*Navigation, located on the right-hand
side
2 Not used 8.1 Remove from stock with a fork cycle
3.1 Creep speed active 8.2 Place into stock with a fork cycle
3.2 Turret head not in the end position
3.3 Telescopic fork not in the end position
At points marked 1 - 8, the pictograms shown
appear depending on the situation and the op-
tions available.
Overview
3
Displays
32 5231 804 2502 EN - 04/2020
