the two monitors. This system therefore
makes it easier to enter the aisle guidance.
Camera system for monitoring the road-
way
One camera mounted on the load wheel axle
under the driver's cab. Shows the roadway in
the load direction. The driver's cab must be
raised by approximately 50 cm for this pur-
pose. A second camera installed centrally on
the lift mast with a view of the drive unit. One
monitor in the driver's cab. Switching takes
place depending on the drive direction.
Maintenance and cleaning
Camera systems are low-maintenance.
During regular maintenance or after particular
events:
– Check that the support mountings for cam-
eras and monitors are in perfect condition.
– Check the clamps for tightness.
– Check the camera settings.
– Clean the camera lenses using lens cloths.
Lift height preselection
NOTE
The optional "lift height preselection" function
is described in detail in separate operating in-
structions.
This function partially automates the approach
to the lift heights. The operator simply has to
enter the required lift height with a number.
The operator then actuates the operating devi-
ces accordingly and the system automatically
brings the load fork to the required height.
In a further configuration level, the controller
recognises whether or not there is a load on
the load fork. Accordingly, the load fork is
brought to the correct height for a storage or
retrieval process.
Special equipment
7
Lift height preselection
138 5231 804 2502 EN - 04/2020
