More detailed information can be found in the
relevant dedicated chapter.
Inductive guidance (IZF)*
The industrial trucks can be guided
inductively
when travelling within aisles. To achieve this,
a wire is embedded into the floor; this wire is
live with current. The magnetic field generated
by this wire is detected by sensors in the in-
dustrial truck and used to guide the truck.
Two-hand operation is required to make use
of the guidance system. The operator's right
hand selects the driving speed and drive di-
rection. The operator's left hand is used to ac-
tuate a sensor or a function.
More detailed information can be found in the
relevant dedicated chapter.
*Option
Mechanical guidance MZF
The mechanical guidance consists of one or
two rails on or between which the industrial
truck is guided with a maximum permissible
play of 5 mm. When guidance is active, the
controller automatically adapts the maximum
possible driving speed to match the lift height.
Entering the aisle
To enter rail guidance, the industrial truck
must be positioned as centrally as possible
and aligned with the aisle in front of the entry
funnel. The more accurate this positioning, the
faster and more precisely the industrial truck
will be led into the guide. Once the industrial
truck has entered the guide, the side rail
switches are activated. When the rail switches
detect the rail guidance, the MZF mode of op-
eration is automatically selected.
Instead of the "steering wheel" symbol, the
symbol for "guidance" appears in the display.
Exiting the aisle
The industrial truck must be driven completely
out of the aisle. The sensor system for the
Operation
4
Driving
74 5231 804 2502 EN - 04/2020
