Battery on a roller channel
Description
The battery rests on roller channels and can
be installed and removed from the side of the
truck using a battery change frame*. The bat-
tery is secured with clamping devices on both
sides and held in position in this way.
Monitoring
The battery locks are electrically monitored. If
one of the locks is not correctly locked in place
an error message appears in the display and
the truck will stop.
WARNING
Every time before starting work the battery locks (2)
must be checked for perfect condition and function.
* Option
Knurled-head screw
Battery lock
Rubber buffer
1
2
3
Special equipment
7
Battery on a roller channel
122 5231 804 2502 EN - 04/2020
